Outdoor Air Cooled Wall Mounted Digital Signage
| Product name | Specification | Remarks |
outdoor air cooled wall mounted digital signage
| Industrial grade professional display screen | |
| Display area 1209*680mm |
| LED backlight brightness 2000cd/m2 |
| Resolution 1920*1080P |
| Android system |
| Automatically adjust brightness(light sensitive) |
- Appearance effect picture (optional)
Wall mounted type
2. Parameters
| No. | Parts | specification | parameter | remarks |
| 1 | structure | Shell | 1. 1.5 mm galvanized steel plate,
spray outdoor special power on the surface, protection for 7
years. The door takes waterproof structure design, outdoor rubber seal,
meet the IP55 protection grade. | |
| glass | Using industrial grade 6 mm AR explosion-proof glass | |
| 2 | monitor | LCD display area | 55 inch | |
| Aspect Ratio | 16:9 | |
| Resolution | 1920*1080 | |
| Brightness | 2000nit | |
| View angle | 178° level / 178°vertical | |
| Adjust brightness | automatic | |
| Backlight | LED backlight | |
| touch | Touch | no | |
| 3 | Motherboard
| Motherboard | Android system | |
| WIFI | optional | |
| Display software | Support networking program distribution, Local program update, Personal version mode play
| |
| 4 | Electronic control | Power switch | Industrial power | |
| Waterproof speaker | Industrial waterproof high quality 10w speaker | |
| lightening protector | Three level lightning protection(Military quality) | |
| Leakage protector | yes | |
| Timer | Can be set up by the day, week, month automatically switch machine | |
| 5 | Heat dissipating | Intelligent ventilation system | Fan cooling system, | |
| High temperature automatically shutdown machine | |
| 6 | Other | weight | 100KG | |
| 7 | operational parameter | operating temperature | -40℃~+50℃ | |
| operating humidity | 5%~95% | |
| operating humidity | AC 220V/50Hz | |
| Max power consumption | 400W | |
3. Performance description
1 Structure
1.1 The shell is made of 1.5 mm galvanized steel plate, painting
with special outdoor powder
1.2 Shell designed with waterproof structure, meet the IP55
protection grade
1.3 The machine screen protection glass use 6 mm anti glare AR
explosion-proof glass
1.4 The whole machine adopts single door, easy to maintain internal
screen, glass, heat dissipation components and electronic parts.
1.5 The whole machine adopts modular design, convenient
installation and maintenance.
- The installation has been designed at the top of machine,
convenient to unloading.
2 Display
2.1 43inch high brightness screen, 1500 nit brightness, design life
of 50000 h.
2.2 Highlight displays screen can be viewed clearly under the sun
,visual Angle is 178 °.
2.3 Monitor configure automatic photographic system, can change
display brightness according to ambient light.
- Air cooling heat dissipation
3.1 43 inch use centrifugal fan cooling system, professional
special air duct heat dissipation design.
3.2 the whole machine internal and external air are in isolated
state, the internal air through air conditioning circulation to
keep the internal temperature control.
4.1 The motherboard adopt android.
4.2 The machines use industrial-grade switching power, stable and
long life.
4.3 The machines have the leakage, lightning protection
configuration, etc.
4.4 The machines configure the timer can be set up by the day,
week, month to turn on or shutdown machine on time.
4.5 The machines configure over temperature protection, when the
internal temperature is higher than 55 ℃, it will close display
backlighting. Internal temperature drop to 45 ℃ recover normal
working condition.
